Key Specifications
Overview
Quick Details
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
Fentry
Model Number:
FY610
Product name:
Weatherproof High Security Glass Sliding Turnstile with Card Reader
Framework Material:
304 Stainless Steel
Dimension:
1200 * 340 * 990mm
Passage Width:
550mm (One passage)
Passing Direction:
Single directional / Bi-directional
Flow Rate:
35-40 people per minute
Power supply:
AC220V/110V, 50/60Hz
Operation Voltage:
24V DC
Power Consumption:
40W
Net Weight:
80kg
Supply Ability
Supply Ability:
500 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
Commodity:Fentry Weatherproof High Security Glass Sliding Turnstile with Card Reader
Package Type: Export Wooden Box
Product Dimension: L1200 * W340 * H990 mm
Packing Dimension: L1310 * W450 * H1170 mm
Unit Weight: 80kg
Gross Weight: 100kg
CBM: 0.7CBM/pcs
Port
Yantian, Shekou

Product Description

Optical turnstile is designed to control pedestrians entering or exiting restricted areas, usually used of high pedestrian traffic flow in both directions.
The body is made from brushed stainless steel which creates a seamless and elegant access point to blend into most indoor environment.
It can be integrated with any kind of access controller system (e.g.: RFID device, Push button, Fingerprint and Biometric device).
In case of emergency, the Optical Turnstile arm will open automatically to allow free passage.
Optical Turnstiles are suit for elegant and luxury entrance solutions.
-
The whole system runs smoothly, long-life performance, high operation dependability and fast response.
Alarm function, in case of illegal intrusion and reverse intrusion.
Infrared sensor to prevent pinch pedestrians.
Anti-breakthrough function. The gate is locked automatically until opening signal received.
Anti-trailing function, the turnstile will lock if someone wants to burst in without swiping the RFID card.
LED indicator.
Automatic reset function. If the user fail to pass within the prescribed time (default time is 5 seconds), the system will cancel the authority of the current user automatically.
When power off, optical turnstile will open automatically, which is complying with fire safety requirements.

Specifications
Model No. DS610
Framework Material 304 Stainless Steel
Dimension 1200 * 340 * 990mm
Net Weight 80kg
Passage Width 550mm (One passage)
Passing Direction Single directional / Bi-directional
Power Supply AC220V/110V, 50/60Hz
Operation Voltage 24V DC
Power Consumption 40W
Operation Temperature -15 °C – 60 °C
Operation Humidity 0 ~ 95% (No freeze)
Working Environment Indoor / Outdoor (Shelter)
Flow Rate 40-45 people per minute
LED Indicator Yes
Input Dry contact
Emergency Automatic arm open when power off
Communication RS485, TCP/IP
