Ultra HD IR camera for highest resolution at night

Ultra HD IR camera for highest resolution at night

With the DF5400HD-DN/IR Dallmeier introduces a new infrared camera which has been designed specifically for applications requiring images with highest resolution in real-time at day and in the IR mode at night.


The DF5400HD-DN/IR is an Ultra HD camera with integrated IR illumination. Built into an IP66-rated weather-proof enclosure, the camera is designed for both indoor and outdoor applications. The camera is operated with Power over Ethernet (PoE Class 0, IEEE 802.3af) which allows for an easy, quick and cost-effective cabling and commissioning.

The high resolution of the sensor and the sophisticated image processing enable real-time recordings with UHD resolution at a frame rate up to 25/30 fps (2160p/30) with excellent quality.

The automatic day/night operation is supported by a uniform IR illumination by means of semi-covert 850 nm high power LEDs. In the IR mode at night, the camera provides excellent results due to the high infrared sensitivity and thus meets the most demanding requirements in a 24-hour operation.

The camera has a motor-driven megapixel varifocal lens that is perfectly tuned to the image sensor. The adjustment of zoom, focus and iris is made conveniently using a web browser. Manual lens setting directly at the installation site is not required.
The lens is equipped with a P-Iris control providing a precise and automatic adjustment of the optimum aperture. Thus, the camera achieves a much better depth of field than with conventional DC auto iris lenses under almost any lighting conditions. Its Digital Image Shift function allows a comfortable fine adjustment of the captured image section via a web browser ensuring a quick and easy installation of the camera.

The camera’s RAM memory is used by the EdgeStorage function for storing the video stream in case of a network failure. When the network is restored, the SmartBackfill function ensures a fast transmission to the SMAVIA recording system. This stores the video stream with high speed and then continues the recording of the live stream seamlessly.
