Equipped a color LCD and a printer available for all information when alarms, errors or other operations occur.
It finds that combustible gas leaks in industrial environment and daily living environment. When combustible gas alarm system detects that the concentration of combustible gas reaches the alarm value set by the alarm system, the combustible gas alarm will send out sound and light alarm signals to remind people to take safety measures such as evacuation, forced air exhaust and equipment shutdown.
▪ Color menu display
▪ Max 1 loop
▪ Networking Function
▪ Wall-mounted structure ,compact and exquisite
▪ Built-in printer
▪ Strong anti-interference capability

Technical Specifications
Mains supply: AC220V (3A),Voltage range: +10%～-15%
Standby battery: 12V/7AH sealed lead acid battery *2
LCD screen size: 4.3-inch color LCD screen
Operating Environment:
Temperature: 0°C～+40°C;Relative Humidity: ≤95%, non-condensing
Capacity: 255 addressable points
Communication Interface: RS485、CAN、USB
Dimension (L×W×H): 320mm×120mm×400mm

TC5306
Combustible
Gas
Fire
Alarm
Control
Panel
(FACP)
is
the
new
generational
controller
with
powerful,
reliable
and
flexible
function.

The
control
panel
adopts
intelligent
loop
control
mode,
with
up
to
255
alarming
nodes
(addressable
detector)
in
each
loop.
The
loop
is
reliable
with
strong
anti-interference
capability,
convenient
for
commission
and
field
operation.
