ultra long range multi-sensor PTZ infrared day/night laser and thermal surveillance camera
Key Specifications
multi-sensor infrared thermal and laser camera
Type TRC4510S-2075-IP
Detection 8.6km
5th generation uncooled FPA sensor Resolution 336×256 pixel
Spectral range 7.5～14μm, NETD 50mk
Thermal camera 21mm～105mm
1.Electric zoom and focus
2.Special AS & DOE optical zooming lens
3.3CAM high-precision optomechanical design
Field of view 18°～3.4°
IFOV 0.17～0.85mrad
Image processing SDE digital image processing
10 pseudo color and B/W, B/W inverse
AGC & 2X digital amplification
Consumption 15W, 808nm, NIR
Laser angle 0.5°～20°
Cooling Package 1.filled with inert gas seal to prevent oxidation
2.Laser with distributed design with more cooling capacity
Angle and distance matching 1. Automatic tracking or manual fine-tuning intelligent matching
2. DSS digital stepper illumination angle control, unique laser angle and distance matching technology, min 0.1°follow-up zooming
3. Z-super laser angle and magnification matching algorithm, the tracking response time <30ms
4. 0.01°SLM optical axis aiming and locking
CCD 1/1.8'''' CMOS 0.0002lux Star Ultra low-light color
1. 2 megapixel HD, 1920*1080,Automatic ICR switch
2. H.264/MPEG4/MIPEG H.264 video format
3. Video bit rate 32Kbps ~ 16Mbps, 60Hz30 frames / sec
Visible Lens 1. 30～750mm
2. F4.6～360
3. FOV (H)11°～0.5°
4. Close-up 2.5 meter
5. 105mm Large Aperture
Motorized & manual focus, DC8-12V, auto iris, (optional auto focus), DC5V precision potentiometers preset positions, zoom focus feedback
Fog penetration Optical filtering and AFR image processing technology
Housing 1. Material: aluminum alloy, stainless steel fasteners, anti strong winds.
2. Structure: integrated design,
3. The surface coating: PTA three anti-paint, anti-seawater corrosion
4. Protection grade: IP66, waterproof and dustproof
5.Interface: Aviation waterproof plug
