Key Specifications
Key Features :
- Standalone device - ideal for single door system,
controlling electric lock, security system
- Verify via password and or card
- Four types of verification mode for greater security
- Weatherproof design
- Water resistant capability
- LEDs and electronic buzzer
- Provides positive audio-visual feedback
Technical Specification :
- Input Voltage : 12V DC
- Current Consumption : 60mA
- Operating Temperature : 0⁰C ~ +60⁰C
- Carrier Frequency : 125 KHz
- Wiegand Interface : Wiegand 26 bits
- Reading Range : 30~50mm (2”) max
- Indication : Buzzer and LEDs (Red and Green)
- Lock Output Load : Max 3A
- User Capacity : 2000
- Adjustable Door Relay Time : 0 ~ 99seconds
- Dimension : 120 x 74 x 25 mm
- Unit Weight : 200g
