．Operating Voltage:10~24VDC
．Response Time (Rx):50/100/150/200 ms (selectable -by SW1 slide switch-Rx)
．Contact rating:3A/125VAC
．Swivel Housing
．Sensing range:12 meters (39 ft) -outdoor max / 24 meters (78 ft) -indoor max
．Aluminum housing/PC Resin anti-UV cover/ABS side cap
．Anti-tamper circuit triggers alarm if power is cut or end cap is removed
．Slim aluminum housing, anti high-low temperature/fog/rains
．2 or 4/6/8 separate photoelectric beam sensors；Programmable trigger on simultaneous breaking of any single/2 adjacent beams or 2 adjacent beams broken only - selected by JP2 on Rx's side cap
．Terminal block connection
．Alarm: Break one or two adjacent beams
．Tx power adjustment: By VR1 (ON Tx's side cap)
．N.O./N.C./Common relay output
．Mounting hardware included
．No synchronizing wires required
．LED indicator alignment
．Tamper switch
．SizeW: 35mm/H:30mm/L:570mm(BS-200SH)/1050mm(BS-400SH)/1530mm(BS-600SH)/2010mm(BS-800SH)
