Key Specifications
The Innovative and Intelligent LTE routing switch WR329 series is designed to combine functionalities of LTE router and 8-Port switch for Smart Bus applications. It can also be used in roadside cabinets or other industrial applications for ultra-resilient multi-port Ethernet ports to LTE routing. The flexible modular design allows project customizations of enable/disable LTE. Wide Temperature and Ruggedized design allows convenient deployment in existing infra


High Throughput Wireless Performance

•LTE Cat.4, 2x2 MIMO, 150M downlink and 50M uplink

•4G/3G/2G full cellular network compatibility

LTE-E: FDD B1/3/5/7/8/20; TDD B38/40/41

LTE-AU: FDD B1/B2/B3/B4/B5/B7/B8/B28; TDD B40

LTE-CN: FDD B1/3/5//8; TDD B38/39/40/41

LTE-U: FDD B2/B4/B12


Multiple Ethernet ports

•Supports 8x Fast Ethernet ports, provides 100M wire-speed switching

•Supports 1x Gigabit Ethernet WAN port for uplink or NVR

•LAN Switch port to LTE or WAN port routing

•WAN to LTE Redundant


Enhanced Cyber Security for Critical Application

•Firewall for traffic classification, port forwarding

•Support NAT, DMZ for LAN protection

•Support OpenVPN, IPsec for secure connection

•Support HTTPs/SSH secure login


Management Features

•Various configuration paths, including WebGUI, CLI and SNMP

•Support ViewMaster Utility, Remote configuration software utility and NetMaster NMS System

•Redundancy: Supports WAN to LET redundancy, Dual SIM standby

•LLDP topology discovery

•Diagnostic tool includes Radio LED, Ping, TFTP, SNMP Trap, E-mail Alert and System Log

•LTE watchdog, auto-reconnect cellular connection

•OPCuA, Cloud monitoring by request


Rugged Design for Bus, Wayside Surveillance, ITS Application

•Railway EMC: EN50121-4 compliance

•IEC61000-6-2/IEC61000-6-4 heavy industrial EMC

•ITS/Traffic Control: NEMA-TS2 compliance

•Vehicle: E-mark compliance

•Radio RED for CE Marking

•Emission: FCC part 15 B Class A

•Effective heat dissipation design for operating in -40~75°C environmentsstructure under the harsh conditions.


https://www.womaster.eu/products_detail_Smart-City-%EF%BC%86-Industrial-IoT_LTE-%7C-WLAN-Serial-Router_WR329-2xLTE.htm

 Industrial 8+1G port Cellular Ethernet Routing Switch WR329-2xLTE
