Key Specifications

* Sensor Type - 1/3" image sensor optimized for low-light performance
* Active Pixels - 2304 x 1536 (HxV)
* Compression - H.264/MJPEG
* Streaming - Triple simultaneous streams
* Resolution - QXGA(2048x1536), 2304x1296, 1080P, SXGA, 720P, SVGA, D1, 4CIF, VGA, CIF
* Max. Frame Rate - 3MP 4:3 (2048x1536) at 15 fps (NTSC) and 12.5 fps (PAL)
* Max. Frame Rate - 2MP 16:9 (1920x1080) at 30 fps (NTSC) and 25 fps (PAL)
* Day/Night - Mechanical (ICR) D/N Control
* Day/Night Mode - Auto/BW/Color
* Shutter Time - 1/16000s to 1/7.5s Selectable (60Hz);1/16000s to 1/6.25s Selectable (50Hz)
* Minimum Illumination - IR LED OFF: 0.5 Lux @50IRE (Shutter speed: 1/30 sec)
* IR LED ON: - 0 Lux
* Video Output - NTSC: 720 X 480@30fps; PAL: 720 X 576@25fps
* Bit Rate Control - Primary stream bit rate control: CBR/VBR

Messoa LPR606 3MP IP LPR camera
