Key Specifications
Prodct Features:



Support with H.265 video compression;
Support VGA, HDMI full HD output simultaneously;
Support DHCP,FTP,DNS,DDNS,NTP,UPNP,EMAIL,3G,WIFI;
Support ONVIF; access third party;
Support Web, CMS, provide SDK development;
Support Mobile Phone Monitoring(IOS, Android);
Cloud Services, P2P, Alarm Information Push To Phone;
Support Multi-Language;



Product Specifications:

Model:NVR-8104
Main processor:Hi3798M
Operating System:Embedded Linux
System resources:Simultaneous multi-channel real-time recording, playback, network operation, USB backup
Operator interface:16-bit true color graphic menu operation interface, support mouse operation
Preview:1/4
Video input (IP):4CH 5MP / 4CH 3MP / 8CH 1080P realtime
Video compression:H.265 / H.264
Display quality:Max 4K
Playback quality:5MP / 3MP / 1080P
Decode:1CH 5MP / 2CH 3MP / 4CH 1080P realtime
Motion detection:Support(depend on camera)
Audio compression:G.711A
Intercom:Nonsupport
Recording mode:Manual>Alarm>Dynamic Detection>Timing
Local payback:1CH 5MP / 2CH 3MP / 4CH 1080P realtime
Search mode:Search by Time/Calendar/Event/Channel
Space occupation:Video: CIF 4~5G/day*channel, D1 8~10G/day*channel; 960H 12G~20G/day*channel 720P 20~30G/day*channel; 1080P ~40G/day*channel; Audio: 691.2M/day*channel
Record storage:HDD, Network
Backup mode:Network backup, USB hard disk, USB burner, SATA burner
Video output:1ch VGA, 1ch HDMI HD Output
Audio I/O:0/0
Alarm I/O:0/0
Network interface:1*RJ45 10M/100M Adaptive Ethernet port
USB interface:2*USB2.0 ports
HDD:1 SATA(Up to 6TB for each disk)
PTZ control:Control PTZ device by network
ONVIF:Support
Power supply:12V/2A
Power Consumption:<10W(Without HDD)
Work environment:Temperature:0℃-+55℃, Humidity:10%-90%RH, Atm:86kpa-106kp
Dimension:260(Length) x 220 (Width) x 45 (Height)
H.265 4 Channel 5MP NVR support 1HDD up to 8TB
