JM4012 Outdoor CCTV camera housing
TianJin Jan Mekia Electronic Co., ltd
Region: China
Update: 03/31/2010
Key Specifications
(1)Indoor/outdoor application, bottom fasten mode, easy access to installation.
(2)Blower & heater, wiper, IR illuminator are available for your needs.
(3)Designed for small-to-medium CCD camera.
(4)Back-open style, easy access to maintenance.
(5)Die-cast and extruded aluminum construction.IP66 standard.
(6)2UL-glands located at the bottom of the enclosure which diameter is 11mm.
(7)The interior temperature can be reduced 3℃-5℃ by the sunshield.
Input voltage: AC 24V AC220V DC12V 50/60HZ
Input power: Heater: 10W Fan:Blower 1.5W
Operation temperature: -5℃50℃ （With heater, adapt for -35℃）
Material: Construction : Die-cast and extruded aluminum
Dimension of the window:57*67mm
Max camera & lens: 250*90*72.5mm
Dimension of outline: 390(L) *130（H）*140（W）mm
Net Weight: 1.5kg
