COFDM 5km - 10km Long Distance Microwave FPV Video Transmitter

Product Category:Transmission > Wireless Transmission > Microwave
Supplier: Shenzhen Safe Guard Co., Ltd
Region: China
Updated: 2020/11/23

Key Specifications

COFDM 5km - 10km long distance microwave FPV video transmitter
Radio transmitter for audio video covert surveillance equipment (SG-R5000) is military backpack portable uav cofdm video transmitter.

Long range digital transmitter & receive can gather information and news through buildings, electromagnetic interference, mountains.

COFDM video transmitter transmitt DVD grade video and pictures at a speed of 450km/h in city, moutain or ENG UAV .

Wireless video transmitter performs well in NLO, LOS wireless transmissiom and it is used news, sports, recovery.

COFDM 5km - 10km long distance microwave FPV video transmitter has low delay, and it is used as live broasdcast video transmitter.

Frequency;340MHz(default), 300 to 4400 Mhz (1.2GHz, 2.4GHz)
RF Power;5 watt to 10 watt
Voltage;DC12V
Current;3A
Modulation;COFDM 2K QPSK
Bandwidth;2 , 2.5, 4, or 8 Mhz
Transfer Rate;6 or 8 Mbps
FEC;1/2
Guard Interval;1/32
Video Input;1 ling PAL / NTSC anolog video
Audio Input;Anolog stereo left and right channels
Video Compression;MPEG-2 4:2:0
RF Interface;N
Work Environment;BNC
Video Format;PAL / NTSC
Transmission Range;1km to 10km
size;200x130x60mm
weight;1.5kg (with antenna)
