  • AAS Tech / UTP BALUN

  • Country: Taiwan
  • City: Taipei
  • Address: Guiyang St Sec 2, 160-1, 4 Fl
  • Contact Person: JO Tsung
Key Specifications
VBP24DC-16 is a passive video balun power hub device capable of transmitting 16 channels of baseband video signal and providing 12 VDC power for all 16 channels at the same time using UTP cable. These devices are designed to be used with VBP2412DC passive video and power assurance balun. Passive video signal transmission up to 1000ft / 300m and provide the camera with 12 V DC @ 300mA maximum. Built-in Lightning surge protection and interference rejection.

Features:

--Using UTP cable to transmit video signal and provide power to camera at the same time

--Low cost on cabling, save time on installation and trouble shooting

--Transmission distance up to 1000ft / 300m

--Support all baseband signal formats including PAL, NTSC and SECAM

--International power input support 100-240 V, very efficient power converter and save energy

--Regulated 24V DC output power

--Using 3 pairs of UTP cabling to carry more current

--Over current protection and trouble indicator LED

--RJ45 jack design for easy connection

--Connector reverse polarity and short circuits protection design

--Built-in Lightning surge protection and Interference Rejection

--Low noise exhaust fan ensure system stability

--Main power switch with indicator light

--Rackmount Ear included

16 Channel Video & Power Server  VBP24DC-16
