iCarvisions’s JH4-HD High Definition model is a Hybrid MDVR. Supports 4 channels 960H analog with synchronized video / audio
and playback. It use ARM Cortex A9 high speed processor and Linux operation system, associated with most advanced techniques,
such as image compression of H.264, 3G/4G, GPS, Wi-Fi etc. which can achieve D1/960H/720P/1080P real-time video/audio recording, vehicle trace recording, uploading of GPS, video, audio and alarm, it can also achieve real-time monitoring, alarm linkage
and video reply through our software. JH4-HD implemented with high techniques like vibration proof, dust proof and heat dissipation
It has good expansibility, stable, easy to mount and maintains. The JH4-HD can be used for all kind of vehicles.
- high definition real-time recording with 4 x analog cameras + 4 x 720p IP camera, or 4 x analog camera + 2 x 1080p IP cameras, IPC:12V power supply
- Synchronized 4 channels video & 2 channels audio recording and playback
- 4 channels D1 Full frame recording
- Built-in 2.5 inch hard disk, 2TB storage, excellent shock absorption design
- Build-in G-sensor module
- Built-in GPS module
- Built-in temperature sensor
- Built-in 3G module, HSUPA / HSDPA / WCDMA / EVDO / TD-SCDMA
- Built-in 4G module, 4G LTE module
- Built-in 1 SD card slot for data backup in case of hard disk drive error
-8Channels alarm input and 1 channel alarm output.
-1 RS485 port for PTZ control or Data Device usage
-2 RS232 port for communication or data usage
-1 RJ45 Network port for connection to an IP camera with maximum of 1080P
- Two USB2.0 high speed interface, the front one to derive video files & upgrade software, the back one to connect waterproof & fireproof "black box" for data recorders. The back one is optional.
- 8 seconds delay power-off for data protection
- Hard disk low temperature startup, automatic heating
- Operating temperature -40℃ ~ +80℃
- 8V-36V wide voltage power supply
- Dimension(L×W×H): 192×184×61 mm
- Used in bus, taxi, goods van, school bus, police car, escort car, tanker truck etc.
And we have below more models(3G/4G/WIFI/GPS are optional) :
SD card MDVR:
4 CHANNEL+1 IPC Dual SD CARD MOBILE DVR )JS2-HD
4 CHANNEL+1 IPC G-SENSOR H 264 MOBILE DVR JH4-HD
8 CHANNEL+1 IPC H264 G-SENSOR MOBILE MDVR JH8-HD
HDD/SSD HYBRID MDVR:
4 CHANNEL+4IPC G-SENSOR H 264 HYBRID MOBILE DVR/NVR JH4-HYBRID
8 CHANNEL+4 IPC H264 G-SENSOR HYBRID MOBILE DVR/NVR JH8-HYBRID
Waterproof SSD/HDD MDVR:
4 CHANNEL+1IPC H264 G-SENSOR MOBILE DVRJH6S-4HD
8 CHANNEL+1 IPC H264 G-SENSOR MOBILE DVR JH6S-8HD
Waterproof SSD MDVR:
4 CHANNEL+1IPC G-SENSOR H. 264 MOBILE DVR JH0
All our MDVR support Fuel Sensor, Temperature sensor, Press To Talk, RFID Reader, Driver Panic Button,Driver Fatigue Sensor, UPS , Fireproof Box, etc.
We Supply Analog vehicle camera, AHD vehicle camera and IP vehicle camera
We developed our own IVMS(Intelligent Vehicle Monitoring System), includes IVMS server, IVMS web, IVMS PC Client and IVMS Phone Client( Available download on the Appstore and Google play)
Welcome to inquiry us!
