?Face Plate: 192Lx25WX37H(mm)

?Strike: 100Lx25Wx3H(mm)

?Bolt: 17mmDIA,stainless steel 13mm throw

?Voltage: DC12V(DC24V)

?Start Current: 900mA

?Standby Current: 120mA

?Solid Bolt: polishing housing, 1000Kg Holding Force

?Suitable For: Woodeng Door,Glass Door,Metal Door,PVC Door

?Signal Output: Door Status Output,NO/NC/COM

?Surface Temp: Low Temperature

?Induction Distance: 8mm

?Operating temp: -10~+25℃（14-131F）

?Operating Humidity: 0~90%(non-condensing)

?Special Designed: Tested to 500000 cycles

?Face place material：High Aluminum,Carrulous Line Finished

?Weight: 0.676kg
