Channel 4CH Video+1CH TV

Video Input / Output NTSC/PAL: BNC 4CH In /1CH Out

Audio Input / Output 4CH RCA Input; 1CH RCA Output

VGA Output Yes

Display Resolution NTSC : 720x480; PAL: 720x576

Recording Resolution & Frame Rate NTSC:120fps@CIF; 120fps@halfD1; 60fps@D1

PAL:100fps@CIF; 100fps@halfD1; 50fps@D1

Compression Format Video: H.264 Baseline Profile,

Audio: G.711

Hard Disk Capacity Up to 2TB, SATA interface HDD×1

Recording Mode Manual/ schedule/sensor trigger/motion detection/power-on auto record

Sensors, Alarm 4CH Input, 1CH Output

Network Interface 1 RJ45 10/100Mbps Ethernet

Media Backup 1 USB 2.0 port for USB flash disk, DVD+RW, HDD

PTZ Control RS-485

IR Remote Control Unit Yes

USB Mouse Yes

Operating Temperature -10℃~+40℃

Power Supply DC 12V

Dimensions (L×W×H) 315×232×57mm

Three major innovations (SMS / MMS Alert, Phone Monitoring, Streaming TV)

1. When sensor trigger or motion detection alarm occurs, DVR will send a text message via SMS or snapshot of the scene by MMS. DVR supports up to six phone numbers simultaneously with mix of SMS or MMS.

2. User can dial DVR to hear live audio via DVR’s external microphone. Two-way conferencing is supported.

3. Watch TV through internet via your DVR and local cable signal. Support TV channel switching from internet and can also choose between TV and camera signal. Record and playback at your leisure, your local sports match or TV show.
