Detect the parameter for the various indoor air, such as CO2,temperature, humidity and VOC.

Compact size and low price.

Control devices such as air conditioning automatically.

Technical parameter

Working Temperature Range

-10 ~ 50℃

Working Humidity Range

0 ~ 95%RH

Storing Temperature Range

-20 ~ 60℃

Power Input

Battery 12V

Current Consumption

Average value is 50mA, peak value is 300mA

Dimension

75W x 120H x 22D (mm)

Detection Mode

NDIR

Detection Range

0~2,000ppm / 0~5,000ppm / 0~10,000ppm（optional）

Detecting Accuracy

±30ppm±5% Reading data（0 ～ 50℃）

Sampling time

3 sec

Response time (90%)

≤ 30 sec

Measuring range

-20 ~ 60℃

Precision

±1℃

Detection Range

0 ~ 95%RH

Accuracy

±5%RH

Detection Gas

TVOC, HC etc

Detection Mode

Semiconductor Technology
