Frequency 1.4G (Customizable)

Bandwidth 1/2/5/10/20/40MHz(Adjustable)

Nodes 32/64/128(Customizable)

Transmission range 250KM (Air To Ground)

Power supply

Operation voltage DC12-24V

Current 1.6A

Interface SMA/USB 2.0/RS422/RJ45/HDMI,SBUS(Customizable)

Sensitivity -106dBm

Baud rate 115200bps（adjustable）

RF connector N-type

Encryption AES128 / AES256/user-defined

Operation temperature -20°C ~ +55°C

Storage temperature -40°C ~ +70°C

Size: 78mm*144mm*65mm(Customizable)

Weight Appr 800g (Customizable)
