1) Strong ability of anti-interference, diffraction and penetration;

2) Very suitable for basements, mines, caves, mountains and other environments with obstacles;

3) High quality with high-tech;Safety with AES128bits encryption;

4) Transmit distance can up to about 100km LOS distance in open air/50-60km NLOS in suburb environment;

5) Common video interfaces, connect to an ordinary analogic camera directly;

6) Water-proof, AC 220V(can be ordered 12-28V for solar power interface), adopted different cores in order to distinguish from other interfaces, prevent from destroying the equipment by accident;

7) Support LOS and NLOS transmission,mobile or stationary monitoring.

Frequency;300-900MHz(optional),1.2GHz/2.4GHz/4.4GHz(customized)

RF Power;30W/50W/80W/100W(option)

Video interface: HDMI,SDI, BNC

Transmit distance;100km max LOS distance/50-60km NLOS in suburb

Power Supply;DC12V 7.8A / AC220V 5A

carrier frequency;6.5MHz

Differential gain;5%

SNR;55dB

Work environment;-35~+55°C

Size;400*230*160mm or other size

Weight;8kg(2U chassis)
