Radio transmitter for audio video covert surveillance equipment (SG-R5000) is military backpack portable uav cofdm video transmitter.

Long range digital transmitter & receive can gather information and news through buildings, electromagnetic interference, mountains.

COFDM video transmitter transmitt DVD grade video and pictures at a speed of 450km/h in city, moutain or ENG UAV .

Wireless video transmitter performs well in NLO, LOS wireless transmissiom and it is used news, sports, recovery.

COFDM 5km - 10km long distance microwave FPV video transmitter has low delay, and it is used as live broasdcast video transmitter.

Frequency;340MHz(default), 300 to 4400 Mhz (1.2GHz, 2.4GHz)

RF Power;5 watt to 10 watt

Voltage;DC12V

Current;3A

Modulation;COFDM 2K QPSK

Bandwidth;2 , 2.5, 4, or 8 Mhz

Transfer Rate;6 or 8 Mbps

FEC;1/2

Guard Interval;1/32

Video Input;1 ling PAL / NTSC anolog video

Audio Input;Anolog stereo left and right channels

Video Compression;MPEG-2 4:2:0

RF Interface;N

Work Environment;BNC

Video Format;PAL / NTSC

Transmission Range;1km to 10km

size;200x130x60mm

weight;1.5kg (with antenna)
