◊ 360 degree full range viewing, High definition megapixel promise immersive experience

◊ Support 1.3Mp/2Mp optional

◊ H.264 compression, Support Dual Stream, smooth and clear image, Suit to local/remote/cross regional Watch

◊ Support P2P(peer to peer) transmission without router setting or mapping

◊ Built-in Stereo speaker and microphone

◊ Electronic PTZ, Horizontal: 360°,Vertical:180°,view angle can be controlled by smart mobile, PC etc.

◊ Support Max.128G SD for store photo and video. Has record management function, user can set time of automatic video recording, also can automatic video recording via motion detecting. Beside,user can remote download video files of SD card by network

◊ Built-in IR-CUT double-filter,3pieces Epistar Arrays IR Leds, IR range up to 50meters

◊ Support UPNP-plug and play function

◊ 1.1mm/1.44mm/1.7mm high quality 3Megapixel lens

◊ Support Android, iPhone etc mobiles watch directly(better quality video when using H.264 format)

◊ Support IE, Firefox, Safar ect. browsers

◊ Support remote watch video and record by internet

◊ Support TCP/IP,HTTP,SMTP,RTSP,FTP,DHCP,DDNS,NTP etc network protocol

◊ Support motion detecting, send alarm signals by email or FTP upload pics etc., Also can send alarm information to alarm server

◊ Support remote watch video and record by internet

◊ Use multi-level usernames and passwords

 Specification

CPU

Operation system

Windows, Linux, iOS, Android etc.

Processor

32Bit RSIC Embedded Processor

Sensor&Lens

Sensor

1/3" or 1/2.8" Megapixel CMOS

performance

Automatic BLC, White Balance and Gain Control

Min. Illumination

0LUX(IR ON)

S/N

>69dB

Lens

Fixed 1.1mm/1.44mm/1.7mm high quality 3Megapixel lens

Video

Compression

H.264 Main Profile, MJPEG/JPEG Baseline

Resolution

1080P/960P,VGA(640*480),QVGA(320*240)

Frames per sec.

1-25fps

Image adjustment

Saturation, brightness, contrast

Night vision

IR

3 pieces Arrays LEDs, IR range50M, Automatic IR-CUT

Audio

Compression

ADPCM

Input

Built-in microphone

Output

Built-in speaker

Network

Internet protocol

TCP/IP,HTTP,ICMP,DHCP,FTP,SMTP, PPPoE, RTSP

Internet port

Built in Wi-Fi 5DBI antenna 802.11b/g/n

Alarm

Motion detecting

Sensitive motion detecting

Alarm inform

Support E-mail, FTP upload and pop - up alarm on mobile

Physical indexes

Power supply

USB,5V2A

Working Environment

-10~50 °C/ 95% RH

Accessories

one power adapter

 Material

 Plastic

Size&weight

95x35mm,260g
