◊Adopts luminance separation and 3D DNR technology,high-resolution, better image

◊No delay,real-time and Hi-fi transport video up to 500M(720P/960P) or 300M(1080P)

◊Supports D1/960H, ISP and TX 2 in 1,and analog Matrix/Distributor etc.

◊ Built-in double IR-CUT filter, No color deviation

◊Adopts Long-life and SMART 36pieces φ5 IR Leds, IR range up to 50meters

◊3.6mm high quality lens, 6mm,8mm and 12mm optional

◊Support BLC (backlight compensation), auto white balance, color reproduction and high, less noise, illumination lower, more stable performance

◊Adopts double glass, the image more clear and bright

◊720p/960p/1080p AHD/CVI/TVI optional

◊Aluminum housing, Weather proof,IP66

Specification:

Model

DLX-HBLA10

DLX-HBLA13

DLX-HBLA20

Pixel

1280x720

1280X960

1920X1080

Signal System

PAL/NTSC

Lens

Fixed focus 3.6mm lens(6,8,12mm optional)

Min. Illumination

0LUX(IR ON)

IR

36pieces φ5 Leds, IR range 50M

BLC

Auto

AGC

Auto

Electronic shutter

1/50(1/60)s to 1/100,000s

S/N

>69dB

Gamma correction

>0.45

Video output

1.0Vp- p75Ω（BNC)

Power

DC12V ±10%

Water proof

IP66

Material

Aluminum

Operating Conditions

-18 °C - 50 °C, Humidity 90% or less (non-condensing)

Dimension

160x60x65mm

Weight

550g
