1.Support Dual-stream,1080P real time 25FPS,960Preal time 30FPS,

720Preal time 30FPS

2.Support RS485 (Alarm,audio optional)

3.Support 255 pre-set points and 6 lines scout auto-tracks

4.Support RTSP, PELCO-P,PELCO-D

5.Handle speed lowest 0.5°/S,highest speed 50°/S

6.12pieces IR array lights, IR range up to 150M

7.IR-CUT, Day/Night Auto-switch

8.Built-in fan as cooler

9.Weather proof,IP66

Specification

Model

DLXHIP20C

DLXHIP20J

Sensor&CPU

1/2.5" CMOS,TI368

1/2.5" CMOS ,TI368

Pixel

2.1 Megapixel

2.1 Megapixel

Chip

China SONY 20X

Original SONY 20X

Operation System

Windows XP, Windows Vista

Min. Illumination

0Lux /F1.2(IR ON)

BLC

On

S/N Ratio

>55dB

Video process

H.264 code, Dual Stream, AVI format, 0.1M~6Mpbs adjustable

White Balance

Auto

Protocol

ONVIF、RTSP、PPPoE、DHCP、TCP/IP、HTTP、UDP、RTP/RTCP、UPNP、FTP、DDNS

Baud rate

1200/2400/4800/9600 optional

AGC

on (low, middle, high) / off

Array IR lights

12PCs,IR range:150M

Ethernet port

1 RJ45 Ethernet port ,10/100M

Alarm, audio

1channel alarm, 1channel audio optional

Analog output

1channel analog video output, support CVBS,PAL/NTSC optional

Optional function

-W(WiFi),-HW(high-power WiFi),-E(POE),-C(EVDO wireless),-G(WCDMA wirless),-J(monitor by mobile)

Power

DC12V,4A (IR on)

Operating Conditions

-45 °C - 75 °C, Humidity 90% or less (non-condensing)

Weight

7kg
