It can connect to smoke exhaust valves, air supply valves, fire dampers, etc., and accept action response signals from the equipment.

Input inspection and output inspection functions.

https://www.vedardsecurity.com/wireless-inputoutput-module-p-104

TCMK5413W wireless input/output module is suitable for installation in public places, factories and other environments. When there is a fire alarm, the module can not only send an alarm signal to the control panel through wireless communication technology after receiving the closing signal, but also output the closing signal for connection with other equipment.

Technical Data

All data is supplied subject to change without notice. Specifications are typical at 24V, 25℃ and 50% RH unless otherwise stated.

Battery CR17450

Rated Operating Voltage 3V

Operating current monitoring current≤14uA , alarm current≤10mA Coding method automatically assigned when networking Radio frequency transmit

power<20dBm

Communication method 470MHz FSK coded bidirectional

Communication distance ≤500m

Operating environment temperature 10℃~+55℃

relative humidity ≤95%

Dimension 101mm*137mm*43mm

Weight 170g

The 470MHz wireless communication technology is adopted, and no embedded wiring is needed, so the engineering installation is convenient and quick; With battery low voltage detection function, it can reflect the battery power situation in time; The microprocessor is used to realize signal processing, and the digital signal is used to communicate with the control panel, which works stable and reliably, and has a good ability to suppress electromagnetic interference.
