2.0MP 1/3” CMOS sensor, 4X optical zoom ( 5MP 4X version is optional);

ONVIF2.4 ; Compatible with HIKVISION ,DAHUA, XM,Video park NVR;

Support TCP/IP,HTTP,DHCP,DNS,DDNS,RTP,RTSP,PPPoE,SMTP,NTP,UPnP protocol;

Strong lightning protection, anti-surge function;

Outside weather-proof level up to IP67, IK10 vandal-proof;

Intelligent IR illumination & power consumption is variable, dependant the zoom factor.

Camera

Model No.: VH-NP2004-S05

SoC: Hi3516E

Sensor: 1/3" CMOS 2MP Sony307

Output Pixel: 1920x1080/30fps 1920x1080/25fps

Lens: 4X f = 2.8mm~12mm (5.1mm~51mm 10X is optional)

BLC: Support

AGC: Auto/manual

WB: Auto/manual/indoor/outdoor

S/N Ratio: ≥50dB

PTZ

Communication Protocol: TCP/IP, HTTP, NTP, IGMP, DHCP, UDP, SMTP, RTP, RTSP, ARP, DDNS, DNS, HTTPS, P2P

Software Control: IE, CMS, Management Platform, App

Mobile View(optional): Android, iPhone

Rotation range: Pan:0~350°,Tilt:0~70º

Rotation speed: Pan:0~25°/s , Tilt:0~20°/s

Preset Points: 220pcs presets(dwell time 01-60s interval available)

A-B scan: Any point in range: 0 to 350 degree and 0 to 70 degree

Guard Tours: 3 groups( Max.16 points, dwell time user selectable)

video compression: H.264/H.265M-JPEG

Operating temperature: -15℃~+60℃

Operation menu: English

Power: DC 12V 1A

Consumption: ≤10W

Lightning Protection: Transient voltage 6000V

Related validation: IP66, CE, FCC, RoHs

IR parameter

Auto Control IR LED: PWM

LEDs: 4 PCS array 42mil IR LED

IR distance: Up to 50 meters

Support ambient light detection: IR illumination on 1-9 grades selectable

Packaging

Each one in inner box, 24PCS/carton.

Carton box size and G.W.: 67*36*49CM, 18KG.
