For Using Single Power Adaptor

--Uses an Unshielded Twisted Pair cable (UTP), to transmit full motion camera video signal in color up to 1000ft / 300m and in B/W up to 2000ft / 600m.

--No power required for video balun

--Surge / Lightning Protection

10/700 μs Pulses: 2KV

Standard: IEC61000-4-5

--ESD : Electrostatic Discharge Protection

Contact Discharge: 6KV / Air Discharge: 8KV

Standard: IEC61000-4-2

--Wave / Interference Rejection & Noise Filter Protection

Built-in Filter: 0~6HMz with Extra Interference Rejection <60db

--DC Power Lead: 12V~24V DC

UTP Balun Cabling Systems and Solutions provides an answer for all your cabling needs. Our complete line of baluns allows you to easily extend your current audio/video/data system up to 1200ft and even up to 8000ft, with an active balun.

UTP Baluns are perfectly suited for applications such as these:

CCTV Security Systems – Video Balun

CCTV Surveillance Systems – Video Balun

CCTV Camera – Video Balun

Home Theatre – DVI & HDMI Balun

LCD/CRT Monitors – VGA PC Balun, VGA Extender, and VGA Distributor

Televisions – DVI & HDMI

VGA Monitors – CCTV Balun, VGA Balun, VGA PC Balun, VGA Extender, and VGA Distributor

DVD Players – DVI & HDMI Balun

PCs (Personal Computers) – VGA Monitor, Keyboard, & Mouse Long Range CAT5E Extender

Laptops/Notebooks – VGA Monitor, Keyboard, & Mouse Long Range CAT5E Extender

USB and PS/2 Devices – VGA Monitor, Keyboard, & Mouse Long Range CAT5E Extender

UTP (Unshielded Twisted Pair Cable) – Cat5E, Cat6 for Extender Balun

BNC (Coaxial Cable) – Video Signal Filter.

How does a balun work?

Baluns are used to convert between “Balanced and Unbalanced” electrical signals.

Baluns work by transforming the original unbalanced (video/power/data/etc.) signal to a balanced frequency used by a different cable, like CAT5 UTP. Not only does this reduce interference, but it also allows you to transmit a signal much longer than the original application would allow. Baluns are always utilized in pairs. One balun is needed to convert the original signal to a new frequency, and another balun is used at the other end to revert to the original frequency.

“Passive” Video Baluns do not require power, and can extend a signal up to 2000ft (B/W).

“Active” Video Baluns require power, but can extend a signal up to 8000ft (B/W).
