Working voltage: AC220±10%V 50±10%HZ

Driving motor: DC24V brush motor

Size: 1600mm (L) * 280mm (W) * 1000mm (H)

Passage width: 300-530mm

Swing arm angle: 180 degree

Direction: single or bi-directional (optional)

Working environment: indoor/outdoor (with a tent over) -10℃～70℃

Relative humidity: ≤90% coagulation free

Time of opening/closing: 1 second

Pass speed: 40 persons/min (open), 25-30 persons/min (closed)

Time to work after power on: 3 seconds

Reset time after break down: 10 seconds

Normal running life: 3 million

Communication interface: standard RS485 interface, distance ≤1200m

Input interface: +12V level signal or pulse width>100ms 12V pulse, drive current>10mA
