Memory RAM：1G; ROM: 4GB

Screen Size(inch): 8 inches（MIPI） IPS

Resolution: 800*1280

Angle of view: full-aspect

Lightness: 500 cd/m2

Camera 2 million pixels，90dbWDR

Visible light field of view: 65°

Identification mode Face, IC card/CPU card

Identification speed Card identification＜0.1s, face identification＜1s

Identification technology Binocular liveness detection，visible light+infrared identification

Identification distance Face+temperature50~200cm(suggestion 100cm)

Face library 20000pcs faces

Camera complementary light 4 Infrared+12White light intelligent fill light; Object induction: microwave

sensor; Light sense: light sensitive sensor

Body temperature Infrared imaging temperature monitoring

FOV(calculated value) 59°× 44°

Resolution 160×120

Temperature measurement

accuracy (room temperature) ± 0.5℃, 0.3℃ after black body calibration

Blackbody target surface 2cm×2cm

Blackbody temperature setting range 

Temperature value from room temperature to 50℃

Voice broadcast  Support

communication  mode Ethernet 10M/100M, WIFI optional

Data transfer protocol UDP, TCP/IP

Port 1 way wiegand input or output;1 way relay;1 way magnetic signal;1 way door button;1 USB;1 RS485;1 power supply

Waterproofing grade IP54

Temperature 0℃-+50℃

Humility 10%-90%

Power supply DC12V 2A

Case material Aluminium alloy (CNC)

Dimension 243*127*32mm(dimension not include post, not include external camera),

Wall mounted/post mounted
