Equipped with dual long focal aspherical lens, combination with sharpening, filtering and DDE imager processing technology, SZ303 has a unique advantage to monitoring air/ground target. Dual-FOV, it helps SZ303 fast capture target in wide FOV and find precise locate in narrow FOV. With digital detail enhancement (DDE) technology, SZ303 offers unmatched image quality. Well-sealed ability and all-weather construction guarantee it high-performance in any harsh environment. SZ303 is absolutely a best choice for detection long distance air and ground target. It can be mounted on tripod or integrated into other system.

Imager Performance

Detector Materials Uncooled FPA

Pixel Size 320×240

Spectral Range 8μm～14μm

NETD ≤45 mK (F/0.7)

FOV 5.8o×4.3o/17.4 o ×12.9 o ~ 4.7 o× 3.5 o /14.1 o ×10.5 o

Frame Frequency 25Hz

Imager Presentation

Electronic Zoom ×2

?Brightness & Contrast Manual / Auto

Offset & Gain Control Automatic

Polarity B&W

Cursor customized

Interfaces

Analog Video NTSC/PAL

Command Interface Ethernet 2.0/RS422/RS232/RS485

Environmental

Operating Temperature -40℃～+65℃
