Resolution:

Color: 500TVL

Black and white: 570TVL

Transforms between color and black/white, automatic change ICR

Supports 4 lines alarm input, 2 lines output (excluding this set in default mode)

English OSD menu, 4 lines pattern and 2-scan mode

Automatic scan and limited position in left/right, speed can be adjusted

RS-485 communication, Pelco-P/D protocol automatic detected

Baud rate (optional): 2,400, 4,800, 9,600 and 19,200bps (255 ADD ID)

8 lines scanning limited in left/right

Technology parameters:

Signal format: PAL and NTSC

4.2-inch high-speed dome

Image sensor: 3.5-inch Sony HAD CCD

Resolution: 440,000 pixels

Lens: total zoom 100, 10x zoom and 10x electronic zoom

Minimum illumination:

Color: 0.7 Lux/F1.8 (50IRE)

B/W: 0.1 Lux/F1.8 (50IRE)

S/N ratio: ≥50dB

White balance: automatic and manual

Expose: automatic, manual, priority and back-light compensation

Focus: automatic and manual (preferential)

Backlight compensation: off, slow, middle and high

Privacy zone: on/off, 4 dynamic tracking privacy zones

Operating button: far and near zoom

Video output:

VBS: 1.0Vp-p (synchronization negative) Y/C

OSD: English

Image automatic-flip: on and off

Black/white mode: automatic, color and BW

Patrol learn: record up to 63 movements

Tilt: 0 to 90°

Pan: 0 to 360°

Power supply: 12V DC

Power consumption: 6W

Operating temperature: -40 to 70°C
