Outdoor station:

Water-resistant shell

Explosion protection

Temperature: -40 to 70°C

Relative humidity range: 45 to 95% RH

Atmospheric pressures: 86 to 108kPa

Protection level: IP33

Working voltage: 12 to 15V DC

Static current: 0.17mA

Working current: 150mA

IR CCD camera

Camera: color 420TVL

Dimensions: 182 x 69 x 50mm

Net weight: 890g

Warranty: one year

Indoor station:

Housing: ABS

Power supplies: 12 to 15V DC

Static current: ≤20mA

Working current: ≤300mA

Screen size: 7-inch color TFT LCD

Dimensions: 235 x 190 x 38mm

Net weight: 768g

Installation: surface mounted

Warranty: one year

Functions:

Dual communication, monitoring, door release

SCM control technology

Using RVV-4 cable for wiring and easy installation

Maximum support of three outdoor station and three indoor phones

Multi-door entry (optional)

Inner calling

Handsfree communication

Adjustable brightness, color, contrast and ring volume

Adjustable talking volume
