2-way communication

Video transmission

Door release

Compatibility of video and audio indoor phone

Humanized design with name input

Power and LED indicators

ID card reader

Maximum capacity: 2 to 12 apartments

Specifications:

(outdoor phone)

Housing: aluminum

Temperature: -40 to 70°C

Relative humidity: 45 to 95%

Atmospheric pressure: 86 to 108kPa

Protection level: IP33

Working voltage: 12 to 15V DC

IR CCD camera

Resolution:

Color: 420TVL

B/W: 480TVL

Installation size: 243 x 105 x 30mm

Installation: flush mounted

Size: 243 x 105 x 30mm

Net weight: 717g

Specifications:

(indoor phone)

Housing: ABS

Temperature: -10 to 70°C

Relative humidity: 45 to 95%

Atmospheric pressure: 86 to 108kPa

Protection level: IP33

Working voltage: 15V DC

Static current: 30mA

Working current: 500mA

Installation: surface mounted

Size: 225 x 190 x 60mm

Net weight: 850g
