Dual communication, monitoring and door release

One button operates one unit room

Humanized design with name input

Power indicator

Capacity: 1 to 16 rooms

Inner calling

Handsfree communication

Capturing image (1GB memory card)

Adjustable brightness, color, contrast of picture and ring volume

Adjustable talking volume

Changeable chord melody (3 tones)

Specifications (indoor phone):

Housing: ABS

Working voltage: 12/15V DC

Static current: 160mA

Working current: 420mA

Screen size: 7 inches color TFT LCD

Dimensions: 220 x 145 x 27mm

Net weight: 466g

Installation: surface-mounted

Warranty: one year

Specifications (outdoor station):

Housing: aluminum

Temperature: -40 to 70 degrees Celsius

Relative humidity: 45 to 95% RH

Atmospheric pressure: 86 to 108Kpa

Protection level: IP33

Working voltage: 12/15V DC

IR CCD camera

Resolution: color 420TVL

Installation: flush-mounted

Dimensions: 316 x 122 x 65mm

Net weight: 1,008g

Warranty: one year
