composition 1R1G1B

Scan method 26S

resolution 104 x52dots (W x H)

Pixel pitch 1.923mm

Leasing LED video screen Module size 200 x 100mm

Module quantity 2x2

resolution 208 x 104(W x H)

Cabinet size 400x 300mm

Waterproof grade IP43

Supply voltage AC 220/110 ± 10 %,47~63Hz

Panel Type and Material Die-casting aluminum

Best viewing distance 10-55m

Maximum power 580W /m2

Viewing angle 140°/120°

Brightness 1000cd/m2

Pixel density 270422dot/m2

Control system Synchronous/Asynchronization System

working temperature -20º C to +50º C

Working humidity 20 % to 90 %

Frame frequency 60Hz

Refresh rate ≥2,400Hz

installation Hanging/Fixed with support bracket
