Lock Size: 150 mm × 25.4 mm × 33 mm

Face Plate: 193 mm × 25.4 mm × 2 mm

Cover: 200 mm × 32 mm × 1.5 mm

Bolt: 15.8 mm

Bolt Depth: 16 mm ± 1 mm

Striker Plate: 102.55 mm × 25.4 mm × 2.5 mm

Surface Temperature: < 40 ℃

Power Input & Tolerance: DC12V / 24V

Current Draw-Pull in: DC12V- 0.98A

DV24V- 0.49A

Current Draw-Holding: DC12V- 0.24A

DC24V- 0.12A

Time Delay: From 0 to 9 sec
