Auto-detective logical (monitored the bolt)

12VDC/24VDC (Jumper)

12VDC-Pull in/0.98A；Holding/0.24A

24VDC-Pull in/0.55A；Holding/0.14A

Time delay: 0/3/6/9 sec. (Dip switch)

Door Status Sensors output (DSS)+ Dual LED

Lock Status Sensors output (LSS)

Lock body-200Lx32Wx35H mm

Striker plate-102.5Lx25.4Wx2 mm

Bolt-15.8D/Deep 16 mm

FCC、CE、RoHS

Brackets: EB-2501HB/EB-2501GJ
