Sensor:1/3 inch Sony super had color ccd (4.9mm x 3.7mm)

Number of pixel:542 (h) x 492 (v) ntsc/512 (h) x 582 (v)pal

Resolution:420 TV lines

D. S. P: Sony d. S. P

Minimum illumination: 0.01 lux (f1.2)

S/n ratio: 50db(agc off)

Electronic shutter: Ntsc:1/60 to 1/100,000 sec/pal:1/50 to 1/100,000 sec

Gamma correction:0.45

Sync system: Inter. Sync.

Lens(option):3.6,4.3,6,8,12mm board lens; f2.0

Backlight compensation: Auto

White balance: Auto

Gain control: Auto agc

Video output:1 vpp composite output,75 ohms

Power source:150ma

Power consumption:2w max

Dimension(mm):118x80mm

Ambient humidity:30-90% rh

Operation temperature: -10-50 c
