Feature
Advanced RTOS; H.264 compression;
Software upgrade via USB;
USB mouse control;
PTZ and network function;
Multi-language versions are selectable;
8008T 7 Inch Hidden TFT monitor (China Patent No. 200730174963.4);
Support mobile remote surveillance;
Support network center management system;
Applied in large surveillance area such as bank,supermarket, gas station, factory etc.
Specification
Model NO. SKY-8008T
Operation System Embedded Linux
Compression H.264
Video Input/Output 8 channel BNC input/2 channel BNC output
Audio Input/Output 8 channel BNC input/1 channel BNC output
Display Frame Rate NTSC: 240 fps (8x30 fps)
PAL: 200 fps (8x25 fps)
Record Frame Rate NTSC: 240 fps (8x30 fps) CIF
PAL: 200 fps (8x25 fps) CIF
Record Mode Manual﹑Schedule﹑Motion Detection
Image Quality CIF
Record Resolution NTSC:352x240(CIF)
PAL:352x288(CIF)
Playing Mode 1 channel
Searching Mode By time/By event/By channel
HDD Support 1TB SATA HDD
Alarm Input/Output 8 channel input/1 channel output
Internet IE/PPPoE/DDNS
Remote Control Yes
Mouse Control USB
USB Port USB 2.0
PTZ Control Yes
Language Support Simplified Chinese,English
7 Inch Hidden TFT Monitor Yes
Software Upgrade USB
Mobile Surveillance Support Symbian s60 v3.0 , Mobile Pocket PC operation system
Power Supply 19V/3.42A DC
Working Temperature -10℃ ~ +50℃
Working Humidity 10%~90%
G.W/N.W 6.1KG/4.5KG
Meas(L*W*H) 330 x 360 x 60mm
