Feature
Advanced RTOS; H.264 compression;
Software upgrade via USB;
USB mouse control;
PTZ and network function;
Multi-language versions are selectable;
15.6 Inch fixed TFT monitor (China Patent No.200930169158.1);
Support mobile remote surveillance;
Support network center management system;
Applied in large surveillance area such as bank,supermarket, gas station, factory etc.
Specification
Model NO. SKY-8016B
Operation System Embedded Linux
Compression H.264
Video Input/Output 16 channel BNC input/2 channel BNC output
Audio Input/Output 16 channel BNC input/1 channel BNC output
Display Frame Rate NTSC: 480 fps (16x30 fps)
PAL: 400 fps (16x25 fps) CIF
Record Frame Rate NTSC: 480 fps (16x30 fps) CIF
PAL: 400 fps (16x25 fps)
Record Mode Manual﹑Schedule﹑Motion Detection
Image Quality CIF
Record Resolution NTSC:352x240(CIF)
PAL:352x288(CIF)
Playing Mode 1 channel
Searching Mode By time/By event/By channel
HDD Support 1TB SATA HDD
Alarm Input/Output 16 channel input/1 channel output
Internet IE/PPPoE/DDNS
Remote Control Yes
Mouse Control USB
USB Port USB 2.0
PTZ Control Yes
Language Support Simplified Chinese,English
Fixed TFT Monitor 15.6 Inch Fixed TFT Monitor
VGA Output Yes
Software Upgrade USB
Mobile Surveillance Support Symbian s60 v3.0 , Mobile Pocket PC operation system
Power Supply 19V/3.42A DC
Working Temperature -10℃ ~ +50℃
Working Humidity 10%~90%
G.W/N.W 7.88KG/6.0KG
Meas(L*W*H) 390 x 270 x 200mm
