- Display device: 18x2 character backlight LCD display and 3 LEDs

- Input device: 16-key keypad with backlight

- Communication interface: RS-485 and Wiegand 26

- Operating voltage: DC 12 ~ 15V

- Current consumption: 250mA max

- Operating temperature: -20oC ~ 60oC

- Dimension: 145mm(L) x 102mm(W) x 31mm(H)

- Operating frequency: 2.4GHz

- Reception sensitivity: -50dbm ~ –90dbm adjustable

- Antenna: Internal or external

- Operating range: 3 ~ 15M

- Output relay contact point sustainable power: 110V/10A

- Magnetic coil input from optical coupled detector for car positioning

- Delay access time, 1 ~ 255 second, adjustable

- Option of build-in EM or Mifare reader
