Main Processor High Performance Embedded Microprocessor

Compress Format Video：H.264 / Audio：G711A

Operation System Embedded Linux

Video System NTSC / PAL(Switching)

Video Input / Output 16CH BNC input 1 × BNC output

1 × SPOT output

1 × VGA output

VGA Resolution Support 800×600 ,1024×768, 1280×1024, 1360×768,1440×900

HDMI output Yes,support real 1080P

Video Loop-out 16CH BNC

Audio Input / Output 16ch input / 1ch output (RCA)

Audio intercom input 2CH,1× BNC;1×Phone Jack

Bit Rate Control Support Variable bit rate / Constants Bit Rate optional

Display Resolution D1：704×576(PAL) , 704×480 (NTSC)

Display Frame Rate Each channel PAL：25 fps / NTSC：30 fps

Record Resolution PAL: CIF(352*288) / HD1(704*288) / D1 (704*576）NTSC: CIF(352*240) / HD1(704*240) / D1 (704*480)(each channel is adjustable)

Record Frame Rate PAL：400 fps @ D1 NTSC：480 fps @ D1

Each channel(D1) PAL：25 fps / NTSC：30 fps

Playback channel Max.16ch Full D1 playback simultaneity realtime,any channel playback at the same time,each channel can be enlarge to full screen

Pentaplex Operation Live display / Record / Playback / Backup / Network / Mobilephone view

Picture Quality Best / Well / Good / Medium / Normal / Bad

HDD Storage Support 8 SATA HDD, each max upto 2TB

Recording Mode Manual / Timer / Motion / Alarm / Remote

Recording Pack Time 15/30/45/60mins（optional）

Backup USB 2.0 flash drive; USB remove HDD; USB remove DVD writer; Network; SATA DVD writer

Playback Mode Normal / Rewind / Forward / Manual

Motion Detection Configurable detection areas(22*18 blocks) and Sensitivity

Alarm & Sensor 16ch alarm input / 4ch alarm output

Alarm Relay Output 30V DC 2A/ 125V AC 1A

Alarm Mode Motion Detection / Sensor Triggered / Loss Video / HDD Full or Error

PTZ Control Yes,built-in 1 RS-485,support PELCO-P and PELCO-D

Key board Control Yes,built-in RS232 interface

USB Port 2 USB Port,Support USB Thumb Drive Backup or Upgrade / Mouse / Removable HDD

Network Interface 1 RJ-45 port, 10M1000M

Network Function IE Viewer / Live Monitoring / DVR Setting / Mobile & Email Function/ NTP funtion

Network Protocol TCP/IP、DHCP、UDP、DDNS、PPPOE、FTP、NTP

IE remote View Support WAN remote view upto 10 users simultaneously

Software Support CMS

Mobilephone View Yes,support WinCE; IPhone; Blackberry; Symbian; Android and 3G

IR Remote / USB Mouse Including

Video Loss Detection YES

Log Record Function YES

Key Lock(Password protection) YES

Power-down Recovery Function YES

Power Supply AC 110~230V, 50Hz/60Hz

Power Consumption <16W(HDD not included)

Working Temperature -10℃~+55℃

Working Humidity 10%~90% RH

Size(mm) 440*460*89mm / Standard 2U case
