Specification

Compression

H.264 main profile

User Interface

OSD Menu

Recording Channels

4 video input, 4 audio input

Video Resolution

2D1& 2CIF / 4HD1 / 4CIF

Quality Settings

Adjustable, 5 levels

Recording Rate

1-30FPS (NTSC) per camera

1-25FPS(PAL) per camera

Storage Capacity

32GB SDHC

Record Mode

Timed Shut down/ Ignition/ Post Shutdown

Auto Overwrite

Selectable On/Off

Network

LAN port (TCP/IP)

WCDMA/EV-DO/GPRS

802.11b/g/n

Display Mode

Quad in LCD monitor and MDVR Player

Playback Rate

2X, 4X, 8X, 16X

Search Function

Segment, Alarm, Date/Time

PTZ

1x 485

Battery Backup

Time & Program info (5 years)

Delay On/Off

Selectable 0 to 120 min

Smart Speed

Record the speed of the vehicle

Accelerometer

± 8G G-sensor

Alarm

4 sensors in put

Pre-alarm

5-25 seconds

GPS Ready

Google Map Tracking(optional)

On-Screen Display

Time & Date, Speed

Temperature

-20℃ to 60℃

Voltage Range

8 to 48V DC

Dimensions

42x168x135mm (H x W x D)

Gross Weight

1.1Kg( ( GPS/3G/WIFI modules for Optional))
