* 3.6MM Lens

* 12 Led light,8-10M Infrared Lamp Range

* H.264 Compression Format

* Support P2P

* Transmission up to 15FPS/2MP

* Support two way audio

* DC 5V,2A.

* Support latest Onvif protocol Item

SEC2MHS1

Device

2.0 Megapixel CMOS Sensor

Size

1/4 inch

Effective Pixels

2MP:1600*1200,1MP:1280*720

Min.Scene Illumination

Color

0.5 LUX(IR ON)

B/W

Yes

IR Sensitivity

Yes

IR Cut

Yes

Lens

Lens

3.6mm

Viewing Angle

Horizontal355° vertical 90°

Linux System

Internal Linux system

Day/Nigh

IR distance

8-10 M

Functions

Motion Detection

Yes

BLC

Yes

AGC

Auto

White Balance

Fixed Aperture F1.2

S/N Ratio

S/N Ratio

>50 dB

Video Compression

Compression

H.264

Picture Resolution

Main Flow:

1600*1200 / 15fps

1280*720 / 25fps

Minor Flow:

640*360 / 25fps

160*112 / 25fps

Bit Rate

32 K~ 4.0 M bps

Image Frame Rate

15 FPS

Audio

Compression

G.711

Two way audio

support

Alarm I/O

Alarm I/O

1 channel in/out put

Network

Ethernet

Ethernet (10/100 Base-T),RJ-45 connector

Protocol

HTTP/DHCP/IP/TCP/UDP/DDNS/RTSP/SMTP; WIFI/ 802.11/b/g

Software

Web Browser

support Internet Explorer, Firefox, Google

Mobile phone

Support Iphone, Android

Remote

Support DDNS, P2P

Operating

Temperature

-10°~60°C

Humidity

20-80%

Power

Power Comsumption

DC 5V,2A

Physical

Dimension

100*99*118MM L*W*H

Weight

0.5KG

Approvals

Certification

CE ,FCC
