- Total resources: 4 channels D1 at real time (100fps/120fps).

- Support 32GB or 64GB Class 10 SDHC card storage.

- Built-in heater.

- Built-in GPS for location tracking.

- FS3.0 file system for data reliability and data recovery.

- Certificate: CE, FCC, ISO7637, ISO16750.

Specification

Function Overview

Recording, playback, GPS location tracking

System

OS

Embedded real-time Linux

Control Mode

IR remote control, CP3

Input

4 channels (Aviation-din X4)

Video

Output

1 channel (Aviation-din or RCA)

Video System

NTSC/PAL

Input

4 channels (Aviation-din X4)

Audio

(Note: The frame rate setup must be above 6fps)

Output

1 channel (Aviation-din or RCA)

Display Split

1/4

Display

OSD

GPS information, alarm, voltage, firmware version, MCU version, device information

Operation Interface

Semi-transparent GUI

Video/Audio Compression

H.264/ADPCM

Image Resolution

PAL: D1 (704*576),HD1 (704*288), CIF (352*288)

NTSC: D1 (704*480), HD1 (704*240), CIF (352*240)

Image Quality

1~8 levels adjustable (1 is the best)

Recording

Recording Mode

General/schedule/alarm/ (sensor trigger, speed, video loss)

File Packing Time

15 minutes

Pre-recording

Maximum 15 minutes

Post-recording

Maximum 30 minutes

Playback Channel

1/4 (1 channel by local playback, 4 channels by playback software)

Playback & Backup

Search Mode

Date/time, channel, file type

Backup Mode

USB

Storage

SD Card

32GB/64GB class 10 SDHC card

USB

USB 2.0 × 1

RS485

RS485 × 1

Interface

Sensor

8 inputs, 2 outputs

GPS

GPS location tracking, speed detection and sync time

UPS

Uninterrupted power supply for MDVR

Input

8 ~36 V

Power

Output

12V@2A, 5V@1A

Consumption

12W (without cameras and any accessories)
