1. High video quality based on the H.264 High Profile.

2. High resolution recording. Up to mega-pixel for 4 channel(1280x1024) and D1 resolution for 1 channel(704x576).

3. Compact size, much easier for installation.

4. Support from 8VDC to 32VDC, applicable for 12VDC and 24DC vehicles.

5. The recorder provides each camera with stable +12V DC power; DVR can detect the short cut on power circuit.

6. Can use ignition to control the power. Configuable power timer after ignition is off.

7. Support automatic record, event trigger record, schedule record.

8. Can record speed with audio and video. Support overspeed alarm.

9. Support 3 sensors, can record brake, return, right turn, left turn light status into the record file.

10. Use avi format for record file. Compatiable with different player software.

11.Hard disk with a standard FAT32 file system, it can be used directly on the computer, the operation is simple and convenient. SPECIFICATION

　 ITEM NAME SECS8801 SECS8802 SECS8804

VIDEO VIDEO INPUT 1 channel 2 channels 4 channels

VIDEO OUTPUT 1 channel, 1.0V, p-p, 75Ω, BNC

VIDEO FORMAT Support PAL/NTSC

VIDEO COMPRESSION H.264 High Profile

RECORD RESOLUTION 720x576(PAL)/ 1280x512(PAL)/ 1280x1024(PAL)/

720x480(NTSC) 1248x416(NTSC) 1248x832(NTSC)

FRAME RATE 25fps(D1 PAL) 50fps(D1 PAL) 100fps(D1 PAL)

30fps(D1 NTSC) 60fps(D1 NTSC) 120fps(D1 NTSC)

VIDEO BITRATE 660Kbps ~ 1.5Mbps, 1.32Mbps ~ 3Mbps, 4 level video quality 1.98Mbps ~ 4.5Mbps, 4 level video quality

4 level video quality

AUDIO AUDIO INPUT 1 channel 2 channels 4 channels

AUDIO INPUT FORMAT 20KΩ, RCA

AUDIO OUTPUT 1 channel, 500Ω, RCA

AUDIO LEVEL 1V ~2V, p-p

AUDIO COMPRESSION G.711

STORAGE STORAGE Hard Disc, external USB device (memory stick or hard drive）

FILE FORMAT AVI

INTERFACE SENSORS 1 speed sensor, 1 ignition sensor, 3 sensors for brake, return etc.

COM PORT 2 RS232 port, 1 RS485 port

NETWORK RJ45, 10M/100M Ethernet

GPS Support GPS receiver (optional), Synchronize the DVR system time with GPS automatically, can record GPS information along with video and audio. GPS data format: NEMA0183, Baudrate: 4800bps

SOFTWARE PLAYER Specially designed player for the DVR

THIRD PARTY Windows Media Player(Ver 11.0 or above), VLC Media Player(Ver1.0.0 or above)

SOFTWARE

POWER INPUT POWER From +8VDC to +32VDC

POWER OUTPUT DC, +12V@1.5A, +5V@1A

POWER COMSUMPTION Working power: <5W, Strand by power: 0.1W (exclude camera, Hard Disc, monitor)

OTHER WORK TEMPRETURE From -30C ~ +60C

SIZE 18cm X 18cm X 4.2cm (7.1 " x 7.1" x1.65")

WEIGHT 1.0 KG

PACKAGE SIZE AND WEIGHT 36cm X 26cm X 10cm (14.2” x 10.2” x 3.9”), 2.5KG
