Smart uniform irradiation solution improves image quality & monitoring effect.

Leading IR technology provides high efficiency and long life span of LED.

Accurate constant circuit drive develops excellent performance of product.

Power and day/night switch manually controlled.

Fill light for night vision camera.

Indoor/outdoor use, all-weather use.

High integrated solution for easy installation and saving cost.

Support camera video synchronization by strobe control (optional).

Specification

Quantity of LED 6PCS 2W High Power IR LED

Wavelength 850nm

Beam Angle 15°- 90°

IR Distance 130m-20m

Day/night Switch CDS 10-20lux ±10% /Camera Control (optional)

Strobe control Support Hikvision/Dahua strobe control (optional)

Input Voltage AC110-220V

Output Voltage DC12V 2000mA (camera)

Power Consumption LED: 12W

Panel Tempered glass panel

Housing Aluminum Die Casting Housing

Bracket Bottom mount bracket

Working Temperature -40℃ to +60℃(-50℃ to +60℃ with heater)

Cooling Air cooling internal circulation

Blower Included

Protection Level IP66

Color Beige

N.W 4.8KG

G.W 4KG

Packing Dimension 625*250*215mm

Models for selection

Model Beam Angle IR Distance(850nm)

S-HZ58-15-A-IR 15° 130m

S-HZ58-30-A-IR 30° 90m

S-HZ58-45-A-IR 45° 70m

S-HZ58-60-A-IR 60° 60m

S-HZ58-90-A-IR 90° 20m

*IR distance is tested by SONY 1/3" CCD Camera.

To achieve the distance needed, please pay attention to your camera specification and lens before purchase. It is normal phenomenon that distance may vary due to different cameras and lens.
