Smart uniform irradiation solution improves image quality & monitoring effect.

Leading IR technology provides high efficiency and long life span of LED.

Accurate constant circuit drive develops excellent performance of product.

Power and day/night switch manually controlled.

Fill light for night vision camera.

Indoor/outdoor use, all-weather use.

High integrated solution for easy installation and saving cost.

Support camera video synchronization by strobe control (optional).

Specification

Quantity of LED 10PCS 2W High Power IR LED

Wavelength 850nm

Beam Angle 15°- 90°

IR Distance 160m-50m

Day/night Switch CDS 10-20lux ±10% (adjustable)

Input Voltage AC110-220V or DC12V/AC24V

Output Voltage DC12V 1000mA (camera)

Power Consumption LED: 20W

Panel Tempered glass panel

Housing Aluminum Die Casting Housing

Bracket Bottom mount bracket

Working Temperature -40℃ to +60℃(-50℃ to +60℃ with heater)

Cooling Air cooling internal circulation

Blower Included

Protection Level IP66

Color Beige

N.W 3.2KG

G.W 4KG

Packing Dimension 490*235*185mm

Models for selection

Model Beam Angle IR Distance(850nm)

S-HZ33-15-A-IR 15° 160m

S-HZ33-30-A-IR 30° 120m

S-HZ33-45-A-IR 45° 90m

S-HZ33-60-A-IR 60° 80m

S-HZ33-90-A-IR 90° 50m

*IR distance is tested by SONY 1/3" CCD Camera.

To achieve the distance needed, please pay attention to your camera specification and lens before purchase. It is normal phenomenon that distance may vary due to different cameras and lens.
