• Smart uniform irradiation solution improves image quality & monitoring effect.

• Leading LED technology provides high efficiency and long life span of LED

• Accurate constant circuit drive develops excellent performance of product

• Power and day/night switch manually controlled

• Fill light for night vision camera

• Indoor/outdoor use, all-weather use

• High integrated solution for easy installation and saving cost

Specification

Quantity of LED 10PCS High Power White Light LED

Color Temperature 5000K-6500K

Wavelength 400-780nm

Beam Angle 15°- 90°

White Light Distance 70m-10m

Day/night Switch CDS 10-20lux ±10% (adjustable)

Input Voltage DC12V /AC24V

Output Voltage DC12V 1000mA

Power Consumption 20W (adjustable)

Panel Tempered glass panel

Housing Aluminum Die Casting Housing

Bracket Bottom mount bracket

Working Temperature -40℃ to +60℃ (-50℃ to +60℃ with heater)

Cooling Air cooling internal circulation

Blower Included

Protection Level IP66

Color Beige

N.W/G.W 3.3KG/3.85KG

Packing Dimension 482*225*170mm

Bracket (options) Material: Aluminium Alloy

Size: 83*123.9*304mm

N.W/G.W: 0.45KG/0.6KG
