Accurate constant driver circuit develops excellent performance of LED;

Dot matrix super power LED brings high efficacy, low light decay and long service life;

IP66 waterproof and -40℃ to +50℃ working temperature;

TECHNICAL SPECIFICATION

LED type: 12pcs 2W dot-matrix IR LED

Wavelength: 740nm/850nm/940nm

Beam Angle: 15°-60°

Beam Distance: 120m-40m

Bracket: Wall mount bracket

Working Voltage: AC85-265V/DC12-24V/AC24V

Power Consumption: 22W

Day/Night Switch: Auto

Working Temperature: -40℃ to +50℃

Protection Level: IP66

Color: Black

Panel: Tempered glass panel

Housing: Aluminum Die Casting Housing

N.W/G.W: 1.3KG/1.5KG

Dimension: 135*110*91mm

Warranty: 3-5years

Model Beam Angle Viewing distance (850nm)

S-H121-15-A-IR 15° 120m

S-H121-30-A-IR 30° 80m

S-H121-45-A-IR 45° 55m

S-H121-60-A-IR 60° 40m

S-H121-90-A-IR 45° 30m

S-H121-120-A-IR 60° 20m

Viewing distance is tested by SONY 1/3" CCD Camera.

To achieve the distance needed, please pay attention to your camera specification

and lens before purchase. It is normal phenomenon that distance may vary due to

different cameras and lens.
