Model: SZN-3102

Main Processor: High performance MCU

User Interface: RS485 port

LED: 20pcs high brightness LED

Beam Angle: 15°(standard), 30°, 45° (optional)

D/N switch: environmental brightness detection

Strobe Port: frequency strobe, depended on multiple frequency pulse signal from camera, duty ratio can be adjusted

RS485 Port: connect to PC or camera

Parameter Setting: support internal setting such as strobe brightness etc.

Power Supply: AC165~220V

Power Consumption: Average≤40W, Peak:108W

Strobe Brightness Level: 1～5

Trigger Method: electrical level, switching value, RS485 order

Protection level: IP66

Working temperature: -40～+50°C

Storage temperature: -40～+85°C

N.W: 2.5kg

Size: 261*202*90mm
