Deliver high power infrared light for CCTV & IP camera at night time and improve performance of camera to get clear pictures.

30,000 hours lifetime of LED.

3 years warranty.

Qualified Material

Super power dot-matrix IR LED with strong light effect, long service life and low light decline feature. High efficient twice optical lens processing achieves 90% of the luminous efficiency. The housing adopts high thermal conductivity aluminum to enhance heat dispersion property. Stainless steel bracket and screw ensure low maintenance.

Wide Range of Application

Recommended for security at ports, railway systems, border, prisons, traffic LPR/ANPR, ITS as well as large public places surveillance.

Technical Specification

LED type: 6pcs 2W dot-matrix IR LED

Wavelength: 740nm/850nm/940nm

Voltage: AC85-265V/DC12V/AC24V

Power consumption: 13W

Day and night switch: Auto (build in photocell)

Cable length: 1.3meter

Mounting: Wall mounting “U” bracket

Temperature: -40℃ to 50℃

Grade of protection: IP66

Color: White

Housing: Aluminum

Panel: High light transmittance toughened glass

Net weight: 1.0kg

Gross weight: 1.3kg

Dimension: 105*80*88mm

Packing dimension:180*160*135mm

Model for selection

Model Beam angle IR distance(850nm)

S06D-15-IR 15° 90m

S06D-30-IR 30° 65m

S06D-45-IR 45° 45m

S06D-60-IR 60° 25m

S06D-90-IR 90° 18m

S06D-120-IR 120° 13m

To achieve the distance needed, please pay attention to your camera specification and lens before purchase. It is normal phenomenon that distance may vary due to different cameras and lens.
